Sheet -fed Screen Printing Machine

  • 1,2,3,4 Color Printing

  • Max. speed: 1500pcs/h, 2000pcs/h

  • CCD positioning system ensure the accuracy of ±‌ 0.02mm

  • Max printing size: 400mm✖️500mm/500mm✖️700mm

  • 50m,60,90m drying oven for option.

Category:

Description

The 1-Color Sheet -fed Screen CCD Screen Printing Machine is a high-precision  printing equipment integrated with CCD vision positioning system and independent single-color printing station. Adopting continuous roll-to-roll processing technology, the machine delivers high registration accuracy and stable mass production capacity, effectively solving the positioning deviation and low efficiency problems of traditional screen printing equipment.

Widely adaptable to various substrates, it is extensively applied in precision printing for membrane switches, control panels, digital overlays,Flexible Printed Circuits (FPC), PCB, PET films, PC boards, conductive films, automotive interior dashboards, ITO conductive films and other industrial products. With stable tension control and fast job changeover performance, it is an ideal cost-effective printing solution for single-color mass printing processing.

Features

  • Easy Operation PLC control system with intuitive touch screen interface, allowing operators to set parameters, monitor production status and complete adjustments conveniently.

  • High Accuracy & Precision Servo motor system combined with CCD positioning system ensures precise registration and stable printing accuracy, achieving an accuracy of ±0.02 mm.

  • Fast Changeover Screen plates can be changed quickly and easily, reducing setup time and improving production efficiency for different jobs.

Technical Parameters

Max. Printing Size

400mm×500mm

Max. Screen Frame Size

700mm×1150mm

Web Width

50mm-410mm

Max. Printing Speed

1500pcs/h

Max. oven Temeprature

160‌℃

Power Supply

18 kw

Overall Dimension

6500mm×1050mm×1700mm
